Pioneer Pump 2840 GPM (6") Trailer Mounted Electric Start Diesel Trash Pump w/ Deutz TD2.9L Engine

Model:

66S12-PPI-01-D

Write A Review
$68,999.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
This Item Is Built To Order

Pioneer Pump 2840 GPM (6
Pioneer Pump 2840 GPM (6") Trailer Mounted Electric Start Diesel Trash Pump w/ Deutz TD2.9L Engine
Model: 66S12-PPI-01-D
$68,999.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Water Pumps Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Inlet Size

6 Inch

Style

Trash

GPM

2840 Gallons

Engine

Deutz

  • 6" Pioneer Prime Diesel-Driven Centrifugal Pump & Trailer Package
  • Designed and built for the toughest water / waste water environments
  • Provides better flow, higher heads and greater efficiency
  • Ideal for rental, construction, oil and gas, mining, and agricultural markets
  • Deutz D2.9L, 4-Cylinder Diesel Engine (Tier 4 Final)
  • "Common Rail" injection system and highly-efficient combustion process
  • Provides high torque in a compact size, capable of doing the job of a much larger engine
  • Instrument panel w/ oil pressure gauge, voltmeter, hour meter and tachometer
  • Meets US EPA Tier 4 Final with an oxidation catalyst
  • Pioneer Prime - A True Dry-Prime Pump (Run Dry)
  • Self-priming system w/ mechanically driven, diaphragm-style vacuum pump
  • Eliminates the need for water to prime & prevents product carryover
  • Maximizes lift capability and offers quick initial priming
  • Also provides continuous, unattended reprime under auto stop/start conditions
  • Non-Clogging, Enclosed, ASTM A744 CA6NM Stainless Steel Impeller
  • Passes up to 3" diameter spherical solids
  • Ductile Iron, Class 30 Pump Housing
  • Gear driven design helps to reduce wear of parts
  • Provides greater resistance to shock loading to extend pump life
  • ASTM A536 Grade 65-45-12 Ductile Iron Volute, Cover & Suction Spool
  • Robust design for the most demanding pumping applications
  • LOFA CP900 Control Panel w/ Auto-Start Controls
  • Compatible with High/Low level floats (Not Included) and transducers
  • Telemetry ready design to meet the needs of your unique application
  • 75-Gallon Diesel Fuel Tank
  • Provides a minimum operating time of 36 Hours @ 1800 RPM
  • Heavy-Duty, Department Of Transportation (DOT) Compliant Trailer
  • Vibration isolation mounts help extend product life
  • Electric brakes (7-Pin Plug) w/ breakaway switch; Pintle Hitch & Safety Chains
  • Stabilizing Jack; Side Step Fenders; LED Tail Lights & Marker Lights
  • 2-Year Warranty
  • *Requires Loading Dock or Forklift For Delivery*
California residents see
Warning: This product can expose you to chemicals including Diesel engine exhaust which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

66S12-PPI-01-D
specs product image PID-155924
General Information
Product Category
Water Pump
Pump
Gallons Per Minute
2840 Gallons
Inlet Diameter
6 Inch
Outlet Diameter
6 Inch
Self Priming
Yes
Pump Head Material
Cast Iron
Quick Clean Out
Yes
Mechanical Seal Material
Silicon Carbide / Tungsten Carbide
Housing Material
Cast Iron
Impeller Material
Stainless Steel
Solids Handling Size
3 inch
Handles Solids
Yes
Suction Head
28 Feet
Maximum PSI
260
Total Head Lift
182 Feet
Submersible
No
Engine
Engine Brand
Deutz
Starting System
12-Volt Key Start
Continuous Operation
Yes
Low Oil Shutdown
Yes
Horsepower
74 HP
Fuel Tank Size
75 Gallons
Run Time
36 Hours
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Overview
Product Category
Water Pump
Weight
3400 Pounds
Certification
Final Tier 4
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
132 Inches
Product Width
69 Inches
Product Height
74 Inches
Accessories
Lifting Hook
Yes
Wheel Kit
Yes
