Little Giant W5G07S12-32S - 5 GPM 3/4 HP Deep Well Submersible Pump w/ Stainless Steel Dsch. (5 GPM @ 320' - 491' Off) (3W - 230V)

Model:

559188

Write A Review
$2,578.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days

Little Giant W5G07S12-32S - 5 GPM 3/4 HP Deep Well Submersible Pump w/ Stainless Steel Dsch. (5 GPM @ 320' - 491' Off) (3W - 230V)
Little Giant W5G07S12-32S - 5 GPM 3/4 HP Deep Well Submersible Pump w/ Stainless Steel Dsch. (5 GPM @ 320' - 491' Off) (3W - 230V)
Model: 559188
$2,578.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Water Pumps Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Inlet Size

N/A

Style

Deep Well

GPM

5 Gallons

  • The Little Giant W-S Series - W5G07S12-32S Submersible Deep Well Pump
  • 3.9-Inch diameter well pump fits 4-inch diameter driven wells or larger
  • NSF/ANSI 372 certified for potable water
  • 304 Stainless Steel Pump Shell
  • Excellent corrosion-resistance in well water
  • Stainless Steel Discharge & Engineered Stainless Steel Motor Bracket
  • Provides extended pump life in wells with less debris
  • Built-Ins:
  • Check valve helps keep pump from rapid cycling and extends the motor lift
  • Suction screen helps keep debris out protecting the impellers
  • 3/4 HP Motor: 3-Wire (not including ground), 230-Volt Franklin Electric Motor
  • Control box Required (Not Included - Sold Separately)
  • 12-Stage Pump Rated For 5 GPM
  • At 30 PSI it can deliver 5 GPM at a depth of 320 feet
  • Specs:
  • 3/4 HP, 230 Volts; 5 GPM; 3-Wire (plus ground) (Requires control box)
  • 491-ft. Shut-off
  • 1-1/4-inch FNPT discharge; Stainless Steel discharge
  • 1-Year Warranty

Specifications

559188
specs product image PID-153736
General Information
Product Category
Water Pump
Motor
Voltage
230 Volt
Wire
3-Wire
Pump
Gallons Per Minute
5 Gallons
Outlet Diameter
1-1/4 Inch
Pump Head Material
Stainless Steel
Housing Material
Stainless Steel
Impeller Material
Plastic
Maximum PSI
80
Total Head Lift
440 Feet
Max Head
491 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Horsepower
0.75 HP
Overview
Product Category
Water Pump
Weight
33 Pounds
Consumer Warranty
1 Year
Product Length
27.6 Inches
Product Width
3.9 Inches
Product Height
3.9 Inches
Accessories
Control Box
Sold Separately
