Lancaster Pump SKS75 - 17.5 GPM 3/4 HP Cast Iron Shallow Well Jet Pump

Model:

SKS75

Write A Review
$447.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Estimated Availability 2-3 Weeks
  Learn More
Estimated Availability
Secure your place in line to receive this item once the manufacturer has provided us new inventory. Keep in mind orders are fulfilled in the order they are received. If you wish to no longer wait on the item, you are more than welcome to cancel the order. However, please keep in mind you will lose your place in line.
Shipping to60601

Lancaster Pump SKS75 - 17.5 GPM 3/4 HP Cast Iron Shallow Well Jet Pump
Lancaster Pump SKS75 - 17.5 GPM 3/4 HP Cast Iron Shallow Well Jet Pump
Model: SKS75
$447.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Water Pumps Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Inlet Size

1-1/4 Inch

Style

Shallow Well

GPM

17.5 Gallons

  • Keystone 3/4 HP Single-Stage Shallow Well Jet Pump
  • Provides optimal pumping at lifts/depths up to 25'
  • Heavy Duty Cast Iron Construction
  • Gets you much longer life compared to thermoplastic pumps
  • 115/230-Volt Dual Voltage Motor
  • Voltage selector switch allows for easy right under motor cover
  • 3/4 HP Square Flange Motor w/ Capacitor Start
  • Capacitor provides extra torque for easier motor starting
  • Thermal & Overload Protection w/ Automatic Reset
  • Prevents significant damage to the motor during operation
  • Thermoplastic Impeller, Diffuser & In-Line Nozzle/Venturi Valve
  • Engineered for increased overall output and efficiency
  • Stainless Threaded Motor Shaft & Upper/Lower Ball Bearings
  • Minimizes corrosion and provides smoother and cooler operation
  • 1" FNPT Discharge
  • Easily connect this pump to most residential plumbing apps.
  • Built-In Drain Plug
  • Allows for easy servicing and winterizing
  • Note* Includes 20/40 Pressure Switch (Not Shown)
  • 3-Year Warranty

Specifications

SKS75
specs product image PID-57829
General Information
Product Category
Water Pump
Motor
Voltage
120/240 Volt
Pump
Gallons Per Minute
17.5 Gallons
Inlet Diameter
1-1/4 Inch
Outlet Diameter
1 Inch
Pump Head Material
Cast Iron
Pump Housing Drain
Yes
Housing Material
Cast Iron
Impeller Material
Plastic
Suction Head
25 Feet
Maximum PSI
64
Submersible
No
Engine
Oil-Cooled
No
Horsepower
0.75 HP
Overview
Product Category
Water Pump
Assembly Required
Yes
Weight
34.5 Pounds
Consumer Warranty
3 Years
Product Length
17.31 Inches
Product Width
6.75 Inches
Product Height
8.2 Inches
Additional Model Numbers

1-SKS75, SKS75
