Lancaster Pump 3LST7510-2 - 3/4 HP 10 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (3-W 230V) & CB

Model:

2-3LST7510-2

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Lancaster Pump 3LST7510-2 - 3/4 HP 10 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (3-W 230V) & CB
Lancaster Pump 3LST7510-2 - 3/4 HP 10 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (3-W 230V) & CB
Model: 2-3LST7510-2
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Similar Products

Recommended Accessories

Water Pumps Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Optional Accessories 6
$10.00
Only 2 In-Stock
$5.00
Only 3 In-Stock
$5.00
Only 3 In-Stock
$99.99
Factory-Direct
$24.99
Only 3 In-Stock

Features

Inlet Size

N/A

Style

Deep Well

GPM

10 Gallons

  • SURVIVOR T-Series 10 GPM 4" Sub. Well Pump (3-Wire 230V)
  • For 4" I.D. or + Wells (<320'); 3-Wire Starting - Control Box Included
  • 3/4 HP Lancaster HYDRO-FORCE Encapsulated Sub. Motor
  • Continuous duty rated, Capacitor-start induction run (CSIR) - Req. Control Box (Included)
  • Stainless Steel Motor Casing & Splined Shaft End
  • Hermetically sealed, permanently lubricated, for greater heat exchange
  • Built-In Lighting Arrestors & Automatic Reset Overload
  • Provides surge and overhead protection for increased protection
  • 1.25" Stainless Steel Discharge Head, Motor & Cable Support
  • Superior strength and corrosion resistance for maximum life
  • Field replaceable fluted internal check valve & molded jug handles
  • Balanced Teflon® Impregnated Thermoplastic Impellers
  • Reduces overall friction to maximize water flow
  • Fully-Enclosed Thermoplastic Diffusers & Stage Plates w/ SS Wear Surfaces
  • Each stage has separate comp. thrust washer for added protection
  • Heavy wall, High Quality SS Pump Casing & SS Intake Screen
  • Sized inside for perfect stage alignmen; wouldn't snap off during install
  • Stainless Steel Hex Shaft w/ Slotted End For Test Turning
  • Polyurethane bearing (top/end motor shaft) for wear resistance
  • 3/4 HP HYDRO-FORCE Quick-Disconnect Control Box (230V)
  • Includes 230V relay, start capacitor & 2 ground/cable terminals
  • NEMR 3R Outdoor rated, painted steel enclosure, QD components
  • 3-Year Limited Warranty

Specifications

2-3LST7510-2
specs product image PID-57905
General Information
Product Category
Water Pump
Motor
Voltage
240 Volt Single-Phase
Running Amps
9.3
Wire
3-Wire
Pump
Gallons Per Minute
10 Gallons
Outlet Diameter
1-1/4 Inch
Pump Head Material
Stainless Steel
Housing Material
Stainless Steel
Impeller Material
Plastic
Maximum PSI
137
Total Head Lift
320 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Horsepower
0.75 HP
Overview
Product Category
Water Pump
Weight
29 Pounds
Consumer Warranty
3 Years
Product Length
25.63 Inches
Product Width
3.81 Inches
Accessories
Control Box
Yes

Reviews

(1)
Lancaster Pump 2-3LST7510-2 Reviews & Ratings
Verified Buyer
Verified Buyer
Lancaster Pump And BAD Control Box
By Alaskalarryk
Oregon
Purchased 04/12/2023 |
Review Posted 06/20/2023
The pump and control were installed by my pump guy and after only a few days we started having issues. Low intermittent water pressure. We switched back to our holding tank and thought our well was bad. Waited a week and tried again. Worked for about 2 weeks, off and on. We had to call our pump Co. and they determined the control box was junk.
Still waiting to see if they are going to refund me the cost of a new control box and the labor.
Alaskalarryk Recommends This
Was this review helpful?
Rating Breakdown
Features
3/5
icon-review-marker
Quality
3/5
icon-review-marker
Performance
2/5
icon-review-marker
Value
4/5
icon-review-marker
Pros:
Price
