IPT Pumps 4S13XHR - 530 GPM (4") Electric Start Trash Pump w/ Honda GX390 Engine

Model:

4S13XHR

Write A Review
$3,785.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 3-5 Business Days

IPT Pumps 4S13XHR - 530 GPM (4
IPT Pumps 4S13XHR - 530 GPM (4") Electric Start Trash Pump w/ Honda GX390 Engine
Model: 4S13XHR
$3,785.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Water Pumps Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Inlet Size

4 Inch

Style

Trash

GPM

530 Gallons

Engine

Honda GX

  • IPT 4-Inch Portable, Gas-Powered Centrifugal Trash Pump
  • Easily handles leaves, debris, and solids up to 2" diameter
  • Commercial Grade Honda OHV GX390 4-Cycle Engine w/ Electric Start
  • Reliable, technologically advanced & easy to start (Battery Not Included)
  • Provides excellent torque & fuel efficiency
  • Protected By Honda Oil Alert® Warning System
  • Alerts you or shuts engine down if oil reaches an unsafe level
  • Helps to prevent engine seizure due to a low oil condition
  • Cast Aluminum Construction w/ Cast Iron (Volute/Impeller) Wearparts
  • Designed to resist abrasion which helps extend pump life
  • 4-Inch Heavy-Duty Male NPT Suction & Discharge Ports
  • Removable design allows ports to be replaced if damaged/stripped
  • Adjustable Discharge Flange
  • Versatile design, rotates in 90° increments for ease of use
  • Silicon Carbide Mechanical Seal w/ Graphite Impregnated Seat & Viton Elastomers
  • Provides exceptional abrasion and corrosion resistance for maximum performance
  • One Tool Serviceability (Tool Included)
  • Makes this pump extremely easy to service and pump maintenance
  • Heavy Duty Steel Roll Frame w/ Vibration Dampening Feet
  • Protects the pump/engine during transportation & operation
  • Helps prevent "pump-walk" when pump is running
  • Includes 4" Suction Strainer
  • 1-Year Limited Warranty
  • ***Please Note - Requires 12V Battery at least 18AH (Not Included)***
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

4S13XHR
specs product image PID-76533
General Information
Product Category
Water Pump
Motor
Battery Included
Yes
Pump
Gallons Per Minute
530 Gallons
Inlet Diameter
4 Inch
Outlet Diameter
4 Inch
Self Priming
Yes
Pump Head Material
Aluminum
Pump Housing Drain
Yes
Quick Clean Out
No
Mechanical Seal Material
Silicon Carbide
Impeller Material
Cast Iron
Solids Handling Size
2 inch
Handles Solids
Yes
Suction Head
26 Feet
Total Head Lift
103 Feet
Submersible
No
Engine
Engine Brand
Honda GX
Starting System
12-Volt Button Start w/ Recoil
Low Oil Shutdown
Yes
Engine Cycles
4-Cycle
CC
390 cc
Fuel Tank Size
1.6 Gallons
Run Time
2.5 Hours
Overview
Product Category
Water Pump
Weight
200 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
31 Inches
Product Width
22.5 Inches
Product Height
23.6 Inches
UPC
726846524271
Accessories
Tool Kit
Yes
Strainer
Yes
Float Switch
No
Hose Couplings
No
Hose
Sold Separately
Hose Bands
No
Transport Handle
No
Wheel Kit
No
